RPS 20HP 480V 800RPS200, Up to 90FT Head, 400 to 1,030GPM, Stainless Steel Submersible Pump End + Motor
The RPSĀ Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.Ā
ā Ā NSF Drinking Water and UL Compliant
Includes...
- 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor EndĀ
- 6" outlet 800RPS200 400-1,030GPM Pump End, 10" Outside Diameter
- 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motorĀ
- Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire.Ā Wires are not pre-crimped.Ā
Customer Supplied Magnetic Starter Box.Ā
| Total Head | Gallons Per Minute (GPM) |
| No head | 1030 |
| 20 feet | 1030 |
| 30 feetĀ | 1030 |
| 40 feet | 975 |
| 50 feetĀ | 912 |
| 60 feetĀ | 800 |
| 70 feetĀ | 702 |
| 80 feetĀ | 555 |
| 90 feetĀ | 400 |
| Above 90 feetĀ | Size UpĀ for Optimal Performance |
Ā Ā
Product Information
Product Information
Shipping & Returns
Shipping & Returns
RPS 20HP 480V 800RPS200, Up to 90FT Head, 400 to 1,030GPM, Stainless Steel Submersible Pump End + Motor
RPS 20HP 480V 800RPS200, Up to 90FT Head, 400 to 1,030GPM, Stainless Steel Submersible Pump End + Motor
The RPSĀ Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.Ā
ā Ā NSF Drinking Water and UL Compliant
Includes...
- 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor EndĀ
- 6" outlet 800RPS200 400-1,030GPM Pump End, 10" Outside Diameter
- 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motorĀ
- Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire.Ā Wires are not pre-crimped.Ā
Customer Supplied Magnetic Starter Box.Ā
| Total Head | Gallons Per Minute (GPM) |
| No head | 1030 |
| 20 feet | 1030 |
| 30 feetĀ | 1030 |
| 40 feet | 975 |
| 50 feetĀ | 912 |
| 60 feetĀ | 800 |
| 70 feetĀ | 702 |
| 80 feetĀ | 555 |
| 90 feetĀ | 400 |
| Above 90 feetĀ | Size UpĀ for Optimal Performance |
Ā Ā
Original: $8,299.99
-65%$8,299.99
$2,905.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The RPSĀ Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.Ā
ā Ā NSF Drinking Water and UL Compliant
Includes...
- 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor EndĀ
- 6" outlet 800RPS200 400-1,030GPM Pump End, 10" Outside Diameter
- 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motorĀ
- Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire.Ā Wires are not pre-crimped.Ā
Customer Supplied Magnetic Starter Box.Ā
| Total Head | Gallons Per Minute (GPM) |
| No head | 1030 |
| 20 feet | 1030 |
| 30 feetĀ | 1030 |
| 40 feet | 975 |
| 50 feetĀ | 912 |
| 60 feetĀ | 800 |
| 70 feetĀ | 702 |
| 80 feetĀ | 555 |
| 90 feetĀ | 400 |
| Above 90 feetĀ | Size UpĀ for Optimal Performance |
Ā Ā
