RPS 20HP 480V 90RPS200, Up to 650FT Head, 83 to 119GPM, Stainless Steel Submersible Pump End + Motor

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6
Product image 7
Product image 8
Product image 9
Product image 10
Product image 11
Product image 12

RPS 20HP 480V 90RPS200, Up to 650FT Head, 83 to 119GPM, Stainless Steel Submersible Pump End + Motor

RPS 20HP 480V 90RPS200, Up to 650FT Head, 83 to 119GPM, Stainless Steel Submersible Pump End + Motor

The RPSĀ Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.Ā

āœ…Ā  NSF Drinking Water and UL Compliant

Includes...

  • 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor EndĀ
  • 3" outlet 90RPS200 83-119GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motorĀ
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire.Ā Wires are not pre-crimped.Ā

Customer Supplied Magnetic Starter Box.Ā

Total Head Gallons Per Minute (GPM)
No head 119
25 feet 119
50 feetĀ  119
75 feet 119
100 feetĀ  119
125 feetĀ  119
150 feetĀ  119
175 feetĀ  119
200 feetĀ  119
225 feet 119
250 feet 119
275 feet 119
300 feet 119
325 feet 119
350 feet 119
375 feet 119
400 feet 119
425 feet 119
450 feet 119
475 feet 111
500 feetĀ  107
525 feet 104
550 feet 99
575 feet 95
600 feet 92
625 feet 87
650 feet 83
Above 650 feetĀ  Size UpĀ for Optimal Performance

Ā Ā

$1,939.00

Original: $5,539.99

-65%
RPS 20HP 480V 90RPS200, Up to 650FT Head, 83 to 119GPM, Stainless Steel Submersible Pump End + Motorā€”

$5,539.99

$1,939.00

Product Information

Shipping & Returns

Description

The RPSĀ Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.Ā

āœ…Ā  NSF Drinking Water and UL Compliant

Includes...

  • 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor EndĀ
  • 3" outlet 90RPS200 83-119GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motorĀ
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire.Ā Wires are not pre-crimped.Ā

Customer Supplied Magnetic Starter Box.Ā

Total Head Gallons Per Minute (GPM)
No head 119
25 feet 119
50 feetĀ  119
75 feet 119
100 feetĀ  119
125 feetĀ  119
150 feetĀ  119
175 feetĀ  119
200 feetĀ  119
225 feet 119
250 feet 119
275 feet 119
300 feet 119
325 feet 119
350 feet 119
375 feet 119
400 feet 119
425 feet 119
450 feet 119
475 feet 111
500 feetĀ  107
525 feet 104
550 feet 99
575 feet 95
600 feet 92
625 feet 87
650 feet 83
Above 650 feetĀ  Size UpĀ for Optimal Performance

Ā Ā
